Tip Top ECO assembly stand (black / red / silver) Meistverkauft

Tip Top Work stand „ECO“

TIP TOP assembly stand „Green & Clever“ steel, environmentally friendly, no energy costs, the stroke takes place on the back of the device via a gas pressure spring with 800mm stroke, ie double stroke compared to the old mechanical stand. Clamping from the front of the device using a sliding block and eccentric clamp. An angle adjustment enables the clamped wheel to be rotated by approx. 160 °. The assembly stand is equipped with a 3-point clamping system to gently and gently clamp different frame shapes and frame materials such as aluminum or carbon. Height of the swivel unit (center of idlers) = 725mm. The mounting stand can be screwed through 4 holes directly on the floor or on the metal base plate (0.370.704 / 9) available as an accessory. Dimensions including swivel unit width 760 x depth 550 x height 1730mm, weight approx. 60 kg, black
